Laptop CPU ranking list

Buying a laptop is not an easy task. There are so many different models, different configurations. The key component in every laptop is the CPU. In this guide, we are going to help you choose better by ranking all Intel and AMD CPUs purely based on performance. By the way, do not miss our “Recommended Smartphones” list that contains best smartphones for every budget.

Before you look at the CPU rankings, please remember these. Often, we see retailers try to clear older stock and they do not help you to get what is best for you.

Architecture and Fabrication

TL;DR version : Go with latest generation as it can run faster at same clock speed compared to last gen. Also, newer CPUs are also easier to cool, take less power. Overall, it will be a win in all fronts for you.

This is the most important factor. Do not fall for GHz and MHz. With each generation upgrade, the efficiency of CPU and how fast it can handle instructions get better. This way, a newer CPU that runs at lower speed will be faster than previous generation CPU that runs at higher speed. Moreover, you also have to consider fabrication. The lower the fabrication is, the more efficient the CPU gets.

Semiconductor device fabrication is the process used to create the integrated circuits that are present in everyday electrical and electronic devices. It is a multiple-step sequence of photo lithographic and chemical processing steps during which electronic circuits are gradually created on a wafer made of pure semiconducting material. Silicon is almost always used, but various compound semiconductors are used for specialized applications. -Wikipedia

CPUs and GPUs are filled with millions and millions of transistors. In chips, these function more like gates switching on and off, to allow electrons pass. In manufacturing plant, multiple chips are made out of single wafer of silicon. The nm figure that you see in specifications (14nm, 28nm etc) is the size of this transistor. When a company says that their chip is designed on 14nm fabrication process, in layman’s terms, it means that the size of the transistor/gate is 14nm. When the transistor size is reduced, there are various advantages. Electrons travel less distance and this improves efficiency and speed. Transistors require less power to turn on and this reduces amount of power required. As a result, there will be noticeable increase in processing power. Also, with smaller transistor size, the size of cpu decreases allowing phone makers to have more space for other components. For example, the battery can be bigger, niche features can be added, phone can be thinner.

Yield rate increases as manufacturing plants move to lower fabrication process. Take a scenario where the transistors are so big that you can only create two processors from a wafer. If one of these two processor is faulty, the yield rate for the wafer is just 50%. Shrink the size of transistor and now you can create 10 processor from the same wafer. If one is faulty ,the yield rate will be 90%. Now, create 100 processors from same wafer and if 1 is faulty, you have a yield rate of 99%. A smaller fabrication processor not only improves performance and power efficiency, it also lets chip manufacturing companies have higher yield rate, faster production and higher revenue.

Core count

TL;DR version: Do not go lower than 6 cores. This is the bare minimum for today’s requirements, even if it for simple web browsing or light usage. Intel has two different types of cores (Performance and Efficiency cores) in same CPU. All the cores in AMD are performance cores. Go for CPU that has more performance cores. Do not fall for total number of cores. A 10 or 12 total core Intel CPU can be beaten by an 8 core AMD CPU. A (4P + 8E) 12 core Intel CPU can be beaten by their own (6P+4E) 10 core CPU.

Clock speed and power usage

Clock speed is measured in GHz. Power consumption is measured in Watts. Laptop CPUs are rated anywhere from 15W to 157W. For same type of core, the higher the clock speed, higher the performance. But there is a catch here. TDP. As the TDP gets lower, the speed goes down.

Thermal Design Power (TDP)

The faster a CPU runs, the more heat it generates and more power it consumes. Some use the term TDP for heat generated and some use this for power consumed by laptop. For now, we will consider ‘power consumed’. Laptops run on battery power. Unlike a desktop where there is no problem with power draw, laptop CPUs need balance between power and battery life. For this reason, CPU makers set limits for power draw. The lower the TDP is, the lower the performance will be. If you pick a CPU that has very high TDP, you end up with laptop that has poor battery. Ideal TDP for laptops would be around 55W.

AMD Ryzen™ 9 7945HX	Intel Core i9 13980HX	Intel Core i9 13950HX
Intel Core i9 13900HX	Intel Core i9 13900H	Intel Core i7 13850HX
AMD Ryzen™ 9 7845HX	Intel Core i7 13700HX	Intel Core i9 13900HK
Intel Core i9 13905H	Intel Core i7 13650HX	Intel Core i7 13800H
Intel Core i7 13705H	Intel Core i7 13700H	Intel Core i5 13600HX
Intel Core i5 13500HX	AMD Ryzen™ 7 7745HX	AMD Ryzen™ 9 7940HS
AMD Ryzen™ 7 7840HS	Intel Core i7 13620H	Intel Core i5 13450HX
Intel Core i7 1370P	AMD Ryzen™ 7 7840U	AMD Ryzen™ 5 7645HX
AMD Ryzen™ 5 7640HS	AMD Ryzen™ 7 7735HS	AMD Ryzen™ 5 7640U
AMD Ryzen™ 5 7540U	AMD Ryzen™ 7 7736U	AMD Ryzen™ 7 7735U
AMD Ryzen™ 7 7535HS	AMD Ryzen™ 7 7730U	AMD Ryzen™ 5 7535U
AMD Ryzen™ 5 7530U	Intel Core i5 13600H	Intel Core i5 13505H
Intel Core i5 13500H	Intel Core i7 1360P	Intel Core i5 1350P
Intel Core i5 1340P	Intel Core i5 13420H	Intel Core i7 1365U
Intel Core i7 1355U	Intel Core i5 1345U	Intel Core i5 1335U
Intel Core i5 1334U

Here is the order in which we rate the laptop CPUs:

AMD Ryzen™ 9 7945HX

Architecture	Zen 4
CPU Cores	16 (two 8 core chiplets)
Total threads	32
Base Clock	2.45GHz
Boost Clock	5.4GHz
Cache	96MB
Fabrication	5nm
TDP	55W
Memory Type	DDR5, up to 64GB DDR5-5200.
PCIe version	5, 28 lanes.
Max temperature	100°C

Intel Core i9 13980HX

Architecture	Raptor Lake
CPU Cores	24 (8 Performance + 16 Efficiency)
Total threads	32 (16 performance threads and 16 efficiency threads)
Base Clock	2.20 GHz (P Cores)
Boost Clock	5.60GHz (P Cores)
Cache	36MB
Fabrication	10nm (Intel 7)
TDP	55W-157W
Memory Type	Maximum of 128GB. Up to DDR5 5600 MT/s or Up to DDR4 3200 MT/s
PCIe version	5.0, 20 lanes
Max temperature	100°C

Intel Core i9 13950HX

Architecture	Raptor Lake
CPU Cores	24 (8 Performance + 16 Efficiency)
Total threads	32 (16 performance threads and 16 efficiency threads)
Base Clock	2.20 GHz (P Cores)
Boost Clock	5.50GHz (P Cores)
Cache	36MB
Fabrication	10nm (Intel 7)
TDP	45W-157W
Memory Type	Maximum of 128GB. Up to DDR5 5600 MT/s or Up to DDR4 3200 MT/s
PCIe version	5.0, 20 lanes
Max temperature	100°C

Intel Core i9 13900HX

Architecture	Raptor Lake
CPU Cores	24 (8 Performance + 16 Efficiency)
Total threads	32 (16 performance threads and 16 efficiency threads)
Base Clock	2.20 GHz (P Cores)
Boost Clock	5.40GHz (P Cores)
Cache	36MB
Fabrication	10nm (Intel 7)
TDP	45W-157W
Memory Type	Maximum of 128GB. Up to DDR5 5600 MT/s or Up to DDR4 3200 MT/s
PCIe version	5.0, 20 lanes
Max temperature	100°C

Intel Core i9 13900H

Architecture	Raptor Lake
CPU Cores	24 (8 Performance + 16 Efficiency)
Total threads	32 (16 performance threads and 16 efficiency threads)
Base Clock	2.6GHz (P Cores)
Boost Clock	5.40GHz (P Cores)
Cache	24MB
Fabrication	10nm (Intel 7)
TDP	45W-115W
Memory Type	Maximum of 128GB. Up to DDR5 5600 MT/s or DDR4 3200 MT/s or 6400MHz LPDDR5 or 4267MHz LPDDR4X.
PCIe version	5.0 or 4.0, 28 lanes
Max temperature	100°C

Intel Core i7 13850HX

Architecture	Raptor Lake
CPU Cores	20 (8 Performance + 12 Efficiency)
Total threads	28 (16 performance threads and 12 efficiency threads)
Base Clock	2.1GHz (P Cores)
Boost Clock	5.30GHz (P Cores)
Cache	30MB
Fabrication	10nm (Intel 7)
TDP	55W – 157W
Memory Type	Maximum of 128GB. Up to DDR5 5600 MT/s or Up to DDR4 3200 MT/s.
PCIe version	5.0 or 4.0, 20 lanes
Max temperature	100°C

AMD Ryzen™ 9 7845HX

Architecture	Zen 4
CPU Cores	12 (two 6 core chiplets)
Total threads	24
Base Clock	3.0GHz
Boost Clock	5.2GHz
Cache	92MB
Fabrication	5nm
TDP	55W
Memory Type	DDR5, up to 64GB DDR5-5200.
PCIe version	5, 28 lanes.
Max temperature	100°C

Intel Core i7 13700HX

Architecture	Raptor Lake
CPU Cores	16 (8 Performance + 8 Efficiency)
Total threads	24 (16 performance threads and 8 efficiency threads)
Base Clock	2.1GHz (P Cores)
Boost Clock	5.0GHz (P Cores)
Cache	30MB
Fabrication	10nm (Intel 7)
TDP	55W – 157W
Memory Type	Maximum of 128GB. Up to DDR5 4800 MT/s or Up to DDR4 3200 MT/s.
PCIe version	5.0 or 4.0, 20 lanes
Max temperature	100°C

Intel Core i9 13900HK

Architecture	Raptor Lake
CPU Cores	14 (6 Performance + 8 Efficiency)
Total threads	20 (12 performance threads and 8 efficiency threads)
Base Clock	2.6GHz (P Cores)
Boost Clock	5.40GHz (P Cores)
Cache	24MB
Fabrication	10nm (Intel 7)
TDP	35W – 115W
Memory Type	Maximum of 128GB. Up to DDR5 5600 MT/s or Up to DDR4 3200 MT/s.
PCIe version	5.0 or 4.0, 28 lanes
Max temperature	100°C

Intel Core i9 13905H

Architecture	Raptor Lake
CPU Cores	14 (6 Performance + 8 Efficiency)
Total threads	20 (12 performance threads and 8 efficiency threads)
Base Clock	2.6GHz (P Cores)
Boost Clock	5.40GHz (P Cores)
Cache	24MB
Fabrication	10nm (Intel 7)
TDP	45W-157W
Memory Type	Maximum of 128GB. Up to DDR5 5600 MT/s or DDR4 3200 MT/s or 6400MHz LPDDR5 or 4267MHz LPDDR4X.
PCIe version	5.0 or 4.0, 28 lanes
Max temperature	100°C

Intel Core i7 13650HX

Architecture	Raptor Lake
CPU Cores	14 (6 Performance + 8 Efficiency)
Total threads	20 (12 performance threads and 8 efficiency threads)
Base Clock	2.6GHz (P Cores)
Boost Clock	4.9GHz (P Cores)
Cache	24MB
Fabrication	10nm (Intel 7)
TDP	55W – 157W
Memory Type	Maximum of 128GB. Up to DDR5 5200 MT/s or Up to DDR4 3200 MT/s. Up to 6400MHz LPDDR5 or 4267MHz LPDDR4X.
PCIe version	5.0 or 4.0, 20 lanes
Max temperature	100°C

Intel Core i7 13800H

Architecture	Raptor Lake
CPU Cores	14 (6 Performance + 8 Efficiency)
Total threads	20 (12 performance threads and 8 efficiency threads)
Base Clock	2.5GHz (P Cores)
Boost Clock	5.20GHz (P Cores)
Cache	24MB
Fabrication	10nm (Intel 7)
TDP	45W-115W
Memory Type	Maximum of 64GB. Up to DDR5 5200 MT/s or Up to DDR4 3200 MT/s. Up to 6400MHz LPDDR5 or 4267MHz LPDDR4X.
PCIe version	5.0 or 4.0, 20 lanes
Max temperature	100°C

Intel Core i7 13705H

Architecture	Raptor Lake
CPU Cores	14 (6 Performance + 8 Efficiency)
Total threads	20 (12 performance threads and 8 efficiency threads)
Base Clock	2.4GHz (P Cores)
Boost Clock	5.0GHz (P Cores)
Cache	24MB
Fabrication	10nm (Intel 7)
TDP	45W-115W
Memory Type	Maximum of 64GB. Up to DDR5 5200 MT/s or Up to DDR4 3200 MT/s. Up to 6400MHz LPDDR5 or 4267MHz LPDDR4X.
PCIe version	5.0 or 4.0, 20 lanes
Max temperature	100°C

Intel Core i7 13700H

Architecture	Raptor Lake
CPU Cores	14 (6 Performance + 8 Efficiency)
Total threads	20 (12 performance threads and 8 efficiency threads)
Base Clock	2.4GHz (P Cores)
Boost Clock	5.0GHz (P Cores)
Cache	24MB
Fabrication	10nm (Intel 7)
TDP	45W-115W
Memory Type	Maximum of 64GB. Up to DDR5 5200 MT/s or Up to DDR4 3200 MT/s.
PCIe version	5.0 or 4.0, 20 lanes
Max temperature	100°C

Intel Core i5 13600HX

Architecture	Raptor Lake
CPU Cores	14 (6 Performance + 8 Efficiency)
Total threads	20 (12 performance threads and 8 efficiency threads)
Base Clock	2.60GHz (P Cores)
Boost Clock	4.80GHz (P Cores)
Cache	24MB
Fabrication	10nm (Intel 7)
TDP	55W – 157W
Memory Type	Maximum of 128GB. Up to DDR5 4800 MT/s or Up to DDR4 3200 MT/s.
PCIe version	5.0 or 4.0, 20 lanes
Max temperature	100°C

Intel Core i5 13500HX

Architecture	Raptor Lake
CPU Cores	14 (6 Performance + 8 Efficiency)
Total threads	20 (12 performance threads and 8 efficiency threads)
Base Clock	2.50GHz (P Cores)
Boost Clock	4.70GHz (P Cores)
Cache	24MB
Fabrication	10nm (Intel 7)
TDP	55W – 157W
Memory Type	Maximum of 128GB. Up to DDR5 4800 MT/s or Up to DDR4 3200 MT/s.
PCIe version	5.0 or 4.0, 20 lanes
Max temperature	100°C

AMD Ryzen™ 7 7745HX

Architecture	Zen 4
CPU Cores	8 (single 8 core chiplet)
Total threads	16
Base Clock	3.6GHz
Boost Clock	5.1GHz
Cache	44MB
Fabrication	5nm
TDP	55W
Memory Type	DDR5, up to 64GB DDR5-5600
PCIe version	5, 28 lanes.
Max temperature	100°C

AMD Ryzen™ 9 7940HS

Architecture	Zen 4
CPU Cores	8 (single 8 core chiplet)
Total threads	16
Base Clock	4.0GHz
Boost Clock	5.2GHz
Cache	28MB
Fabrication	5nm
TDP	35-54W
Memory Type	DDR5, up to 256GB DDR5-5600 or LPDDR5x-7500
PCIe version	5, 20 lanes.
Max temperature	100°C

AMD Ryzen™ 7 7840HS

Architecture	Zen 4
CPU Cores	8 (single 8 core chiplet)
Total threads	16
Base Clock	3.8GHz
Boost Clock	5.1GHz
Cache	28MB
Fabrication	5nm
TDP	35-54W
Memory Type	DDR5, up to 256GB DDR5-5600 or LPDDR5x-7500.
PCIe version	5, 20 lanes.
Max temperature	100°C

Intel Core i7 13620H

Architecture	Raptor Lake
CPU Cores	10 (6 Performance + 4 Efficiency)
Total threads	16 (12 performance threads and 4 efficiency threads)
Base Clock	2.4GHz (P Cores)
Boost Clock	4.90GHz (P Cores)
Cache	24MB
Fabrication	10nm (Intel 7)
TDP	45W-115W
Memory Type	Maximum of 64GB. Up to DDR5 5200 MT/s or Up to DDR4 3200 MT/s.
PCIe version	5.0 or 4.0, 20 lanes
Max temperature	100°C

Intel Core i5 13450HX

Architecture	Raptor Lake
CPU Cores	10 (6 Performance + 4 Efficiency)
Total threads	16 (12 performance threads and 4 efficiency threads)
Base Clock	2.4GHz (P Cores)
Boost Clock	4.60GHz (P Cores)
Cache	20MB
Fabrication	10nm (Intel 7)
TDP	55W – 157W
Memory Type	Maximum of 64GB. Up to DDR5 4800 MT/s or Up to DDR4 3200 MT/s.
PCIe version	5.0 or 4.0, 20 lanes
Max temperature	100°C

Intel Core i7 1370P

Architecture	Raptor Lake
CPU Cores	14 (6 Performance + 8 Efficiency)
Total threads	20 (12 performance threads and 8 efficiency threads)
Base Clock	1.9GHz (P Cores)
Boost Clock	5.20GHz (P Cores)
Cache	24MB
Fabrication	10nm (Intel 7)
TDP	28W – 64W
Memory Type	Maximum of 64GB. Up to DDR5 5200 MT/s or Up to DDR4 3200 MT/s.
PCIe version	5.0 or 4.0, 20 lanes
Max temperature	100°C

AMD Ryzen™ 7 7840U

Architecture	Zen 4
CPU Cores	8 (single 8 core chiplet)
Total threads	16
Base Clock	3.3GHz
Boost Clock	5.1GHz
Cache	28MB
Fabrication	5nm
TDP	28W
Memory Type	DDR5, up to 256GB DDR5-5600 or LPDDR5x-7500.
PCIe version	5, 20 lanes.
Max temperature	100°C

AMD Ryzen™ 5 7645HX

Architecture	Zen 4
CPU Cores	6 (single 6 core chiplet)
Total threads	12
Base Clock	4.0GHz
Boost Clock	5.0GHz
Cache	40MB
Fabrication	5nm
TDP	35-54W
Memory Type	DDR5, up to 256GB DDR5-5600.
PCIe version	5, 28 lanes.
Max temperature	100°C

AMD Ryzen™ 5 7640HS

Architecture	Zen 4
CPU Cores	6 (single 6 core chiplet)
Total threads	12
Base Clock	4.3GHz
Boost Clock	5.0GHz
Cache	24MB
Fabrication	5nm
TDP	55W
Memory Type	DDR5, up to 256GB DDR5-5600 or LPDDR5x-7500.
PCIe version	5, 20 lanes.
Max temperature	100°C

AMD Ryzen™ 7 7735HS

Architecture	Zen 3
CPU Cores	8 (single 8 core chiplet)
Total threads	16
Base Clock	3.2GHz
Boost Clock	4.75GHz
Cache	24MB
Fabrication	7nm
TDP	35-54W
Memory Type	DDR5, up to 256GB DDR5-5600 or LPDDR5x-7500.
PCIe version	3, 20 or 16 lanes.
Max temperature	95°C

AMD Ryzen™ 5 7640U

Architecture	Zen 4
CPU Cores	6 (single 6 core chiplet)
Total threads	12
Base Clock	3.5GHz
Boost Clock	4.9GHz
Cache	23MB
Fabrication	5nm
TDP	55W
Memory Type	DDR5, up to 256GB DDR5-5600 or LPDDR5x-7500.
PCIe version	5, 20 lanes.
Max temperature	100°C

AMD Ryzen™ 5 7540U

Architecture	Zen 4
CPU Cores	6 (single 6 core chiplet)
Total threads	12
Base Clock	3.2GHz
Boost Clock	4.9GHz
Cache	23MB
Fabrication	5nm
TDP	28W
Memory Type	DDR5, up to 256GB DDR5-5600 or LPDDR5x-7500.
PCIe version	5, 14 lanes.
Max temperature	100°C

AMD Ryzen™ 7 7736U​

Architecture	Zen 3
CPU Cores	8 (single 8 core chiplet)
Total threads	16
Base Clock	2.7GHz
Boost Clock	4.7GHz
Cache	24MB
Fabrication	7nm
TDP	15-28W
Memory Type	DDR4, up to 64GB DDR4-3200 or LPDDR4x-4267.
PCIe version	4, 20 lanes.
Max temperature	95°C

AMD Ryzen™ 7 7735U

Architecture	Zen 3
CPU Cores	8 (single 8 core chiplet)
Total threads	16
Base Clock	2.7GHz
Boost Clock	4.75GHz
Cache	24MB
Fabrication	7nm
TDP	28W
Memory Type	DDR4, up to 64GB DDR4-3200 or LPDDR4x-4267.
PCIe version	4, 20 lanes.
Max temperature	95°C

AMD Ryzen™ 5 7535HS

Architecture	Zen 3
CPU Cores	6 (single 6 core chiplet)
Total threads	12
Base Clock	3.3GHz
Boost Clock	5.1GHz
Cache	22MB
Fabrication	7nm
TDP	35-54W
Memory Type	DDR4, up to 64GB DDR4-3200 or LPDDR4x-4267.
PCIe version	4, 20 or 16 lanes.
Max temperature	95°C

AMD Ryzen™ 7 7730U

Architecture	Zen 3
CPU Cores	8 (single 8 core chiplet)
Total threads	16
Base Clock	2.0GHz
Boost Clock	4.5GHz
Cache	24MB
Fabrication	7nm
TDP	15W
Memory Type	DDR4, up to 64GB DDR4-3200 or LPDDR4x-4267.
PCIe version	4, 20 lanes.
Max temperature	95°C

AMD Ryzen™ 5 7535U

Architecture	Zen 3
CPU Cores	8 (single 8 core chiplet)
Total threads	16
Base Clock	2.7GHz
Boost Clock	4.75GHz
Cache	24MB
Fabrication	7nm
TDP	28W
Memory Type	DDR4, up to 64GB DDR4-3200 or LPDDR4x-4267.
PCIe version	4, 20 lanes.
Max temperature	95°C

AMD Ryzen™ 5 7535U

Architecture	Zen 3
CPU Cores	6 (single 6 core chiplet)
Total threads	12
Base Clock	2.9GHz
Boost Clock	4.55GHz
Cache	22MB
Fabrication	7nm
TDP	28W
Memory Type	DDR4, up to 64GB DDR4-3200 or LPDDR4x-4267.
PCIe version	4, 20 lanes.
Max temperature	95°C

AMD Ryzen™ 5 7530U

Architecture	Zen 3
CPU Cores	6 (single 6 core chiplet)
Total threads	12
Base Clock	2.0GHz
Boost Clock	4.5GHz
Cache	20MB
Fabrication	7nm
TDP	15W
Memory Type	DDR4, up to 64GB DDR4-3200 or LPDDR4x-4267.
PCIe version	3, 20 lanes.
Max temperature	100°C

Intel Core i5 13600H

Architecture	Raptor Lake
CPU Cores	12 (4 Performance + 8 Efficiency)
Total threads	16 (8 performance threads and 8 efficiency threads)
Base Clock	2.8GHz (P Cores)
Boost Clock	4.8GHz (P Cores)
Cache	18MB
Fabrication	10nm (Intel 7)
TDP	45W-95W
Memory Type	Maximum of 64GB. Up to DDR5 5200 MT/s or Up to DDR4 3200 MT/s.
PCIe version	5.0 or 4.0, 20 lanes
Max temperature	100°C

Intel Core i5 13505H

Architecture	Raptor Lake
CPU Cores	12 (4 Performance + 8 Efficiency)
Total threads	16 (8 performance threads and 8 efficiency threads)
Base Clock	2.6GHz (P Cores)
Boost Clock	4.7GHz (P Cores)
Cache	18MB
Fabrication	10nm (Intel 7)
TDP	45W – 115W
Memory Type	Maximum of 64GB. Up to DDR5 5200 MT/s or Up to DDR4 3200 MT/s.
PCIe version	5.0 or 4.0, 20 lanes
Max temperature	100°C

Intel Core i5 13500H

Architecture	Raptor Lake
CPU Cores	12 (4 Performance + 8 Efficiency)
Total threads	16 (8 performance threads and 8 efficiency threads)
Base Clock	2.6GHz (P Cores)
Boost Clock	4.7GHz (P Cores)
Cache	18MB
Fabrication	10nm (Intel 7)
TDP	45W – 95W
Memory Type	Maximum of 64GB. Up to DDR5 5200 MT/s or Up to DDR4 3200 MT/s.
PCIe version	5.0 or 4.0, 20 lanes
Max temperature	100°C

Intel Core i7 1360P

Architecture	Raptor Lake
CPU Cores	12 (4 Performance + 8 Efficiency)
Total threads	16 (8 performance threads and 8 efficiency threads)
Base Clock	2.2GHz (P Cores)
Boost Clock	5.0GHz (P Cores)
Cache	18MB
Fabrication	10nm (Intel 7)
TDP	28W – 64W
Memory Type	Maximum of 64GB. Up to DDR5 5200 MT/s or Up to DDR4 3200 MT/s.
PCIe version	5.0 or 4.0, 20 lanes
Max temperature	100°C

Intel Core i5 1350P

Architecture	Raptor Lake
CPU Cores	12 (4 Performance + 8 Efficiency)
Total threads	16 (8 performance threads and 8 efficiency threads)
Base Clock	1.9GHz (P Cores)
Boost Clock	4.70GHz (P Cores)
Cache	12MB
Fabrication	10nm (Intel 7)
TDP	28W – 64W
Memory Type	Maximum of 64GB. Up to DDR5 5200 MT/s or Up to DDR4 3200 MT/s.
PCIe version	5.0 or 4.0, 20 lanes
Max temperature	100°C

Intel Core i5 1340P

Architecture	Raptor Lake
CPU Cores	12 (4 Performance + 8 Efficiency)
Total threads	16 (8 performance threads and 8 efficiency threads)
Base Clock	1.9GHz (P Cores)
Boost Clock	4.60GHz (P Cores)
Cache	12MB
Fabrication	10nm (Intel 7)
TDP	45W-157W
Memory Type	Maximum of 64GB. Up to DDR5 5200 MT/s or Up to DDR4 3200 MT/s.
PCIe version	5.0 or 4.0, 20 lanes
Max temperature	100°C

Intel Core i5 13420H

Architecture	Raptor Lake
CPU Cores	8 (4 Performance + 4 Efficiency)
Total threads	12 (8 performance threads and 4 efficiency threads)
Base Clock	2.10 GHz (P Cores)
Boost Clock	4.60GHz (P Cores)
Cache	12MB
Fabrication	10nm (Intel 7)
TDP	45W – 95W
Memory Type	Maximum of 64GB. Up to DDR5 5200 MT/s or Up to DDR4 3200 MT/s.
PCIe version	5.0 or 4.0, 20 lanes
Max temperature	100°C

Intel Core i7 1365U

Architecture	Raptor Lake
CPU Cores	10 (2 Performance + 8 Efficiency)
Total threads	12 (4 performance threads and 4 efficiency threads)
Base Clock	1.80 GHz (P Cores)
Boost Clock	5.20GHz (P Cores)
Cache	12MB
Fabrication	10nm (Intel 7)
TDP	15W – 55W
Memory Type	Maximum of 64GB. Up to DDR5 5200 MT/s or Up to DDR4 3200 MT/s.
PCIe version	5.0 or 4.0, 20 lanes
Max temperature	100°C

Intel Core i7 1355U

Architecture	Raptor Lake
CPU Cores	10 (2 Performance + 8 Efficiency)
Total threads	12 (4 performance threads and 4 efficiency threads)
Base Clock	1.70 GHz (P Cores)
Boost Clock	5.20GHz (P Cores)
Cache	12MB
Fabrication	10nm (Intel 7)
TDP	15W – 55W
Memory Type	Maximum of 64GB. Up to DDR5 5200 MT/s or Up to DDR4 3200 MT/s.
PCIe version	5.0 or 4.0, 20 lanes
Max temperature	100°C

Intel Core i5 1345U

Architecture	Raptor Lake
CPU Cores	10 (2 Performance + 8 Efficiency)
Total threads	12 (4 performance threads and 4 efficiency threads)
Base Clock	1.30 GHz (P Cores)
Boost Clock	4.7GHz (P Cores)
Cache	12MB
Fabrication	10nm (Intel 7)
TDP	15W – 55W
Memory Type	Maximum of 64GB. Up to DDR5 5200 MT/s or Up to DDR4 3200 MT/s.
PCIe version	5.0 or 4.0, 20 lanes
Max temperature	100°C

Intel Core i5 1335U

Architecture	Raptor Lake
CPU Cores	10 (2 Performance + 8 Efficiency)
Total threads	12 (4 performance threads and 4 efficiency threads)
Base Clock	1.30 GHz (P Cores)
Boost Clock	4.60GHz (P Cores)
Cache	12MB
Fabrication	10nm (Intel 7)
TDP	15W – 55W
Memory Type	Maximum of 64GB. Up to DDR5 5200 MT/s or Up to DDR4 3200 MT/s.
PCIe version	5.0 or 4.0, 20 lanes
Max temperature	100°C

Intel Core 1334U

Architecture	Raptor Lake
CPU Cores	10 (2 Performance + 8 Efficiency)
Total threads	12 (4 performance threads and 4 efficiency threads)
Base Clock	1.3GHz (P Cores)
Boost Clock	4.60GHz (P Cores)
Cache	12 MB
Fabrication	10nm (Intel 7)
TDP	15W – 55W
Memory Type	Maximum of 64GB. Up to DDR5 5200 MT/s or Up to DDR4 3200 MT/s. Up to 6400MHz.
PCIe version	5.0 or 4.0, 20 lanes
Max temperature	100°C
